KDP 7X High-Strength Alloy 3-Blade Yamaha Outboard Propeller RH - A Class (replaces Yamaha 63V-45952-10 (J), 683-45952-00-EL, SOLAS 3111-093-10)
Part #: 1111-093-100
Hub Type: Pressed-in
KDP Model: 7x Series
Class: A
# of Blades: 3
Rotation: Right
Dimensions: A 9-1/4 x 10
Horsepower: 0 - 20 hp
Engines: Yamaha
KDP 7X SERIES HIGH-STRENGTH ALLOY YAMAHA OUTBOARD PROPELLER (A CLASS) - Pressed in Rubber Hub
SKU #1111-093-100
REPLACES PROPELLER OEM P/N(S):
- YAMAHA 63V-45952-10 (J)
- YAMAHA 683-45952-00-EL
- SOLAS 3111-093-10
KDP PROPELLER SPECIFICATION INFORMATION
KDP Propeller p/n: #1111-093-100
KDP Propeller Series: 7X High-Strength Alloy
Propeller Class: A (2-1/2" Gearcase)
Horsepower Range: 9.9 - 20hp
Propeller Diameter: 9-1/4"
Pitch: 10"
Number of Blades: 3
Rotation: RH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Hub Type: Pressed In Rubber Hub
Number of Splines: 8
Outboard Engine: YAMAHA
YAMAHA COMPATIBLE ENGINE MODELS (2-1/2" Gearcase):
| ENGINE TYPE | YEAR |
|---|---|
| F9.9 (4 Stroke) | 2000 to 2007 |
| F15 (4 Stroke) | 1998 to Newer |
| F20 (4 Stroke) | 2007 to Newer |
| 9.9hp (2 Stroke) | 1984 to 2009 |
| 15hp (2 Stroke) | 1984 to 2009 |
