KDP OXE Diesel E-Class Ultra 7X Interchangeable Marine Propeller Rubber Hub Kit (Aluminum Alloy)

KDP OXE DIESEL E-CLASS ULTRA 7X SERIES INTERCHANGEABLE MARINE PROPELLER RUBBER HUB KIT (Aluminum Alloy)
NOTE: Hub Kit for Interchangeable Marine Propeller (OXE DIESEL)
SKU #7511

HUB KIT INCLUDES:

• Thrust Washer
• Rubber Hub
• After Spacer

KDP ULTRA RUBBER HUB FEATURES:

• Holds up to wide range of Dynamic and Static Loads
• Special formulated rubber compound enabling high power long-term use and cyclic loads
• Excellent vibration and shock-absorbing properties
• High corrosion resistence
• One body construction = conistent daily power loads
• Insert edge design distributes high loads, avoids bending while shifting gears or in the event of propeller striking object
• Resuable if propeller is damaged

KDP INTERCHANGEABLE HUB SPEC INFO
KDP Ultra Rubber Hub Kit p/n: #7511
Used for KDP Propeller Series: Ultra 7X High-Strength Alloy (H.S.A)
Propeller Class: E, E+
Horsepower Range: 115hp & Up
Hub Type: Interchangeable Rubber Hub
Insert Material Type: Aluminum Alloy
Made In: South Korea
Outboard Engine(s): OXE DIESEL

COMPATIBLE OXE DIESEL ENGINE MODEL & YEAR:

ENGINE TYPE	YEAR
125hp (15 Tooth Spline)	ALL YEARS
150hp (15 Tooth Spline)	ALL YEARS
175hp (15 Tooth Spline)	ALL YEARS
200hp (15 Tooth Spline)	ALL YEARS

3 BLADE RH ROTATION E CLASS
List of Compatible KDP Ultra 7X Series High-Strength Alloy Interchangeable Outboard Propellers
NOTE: for more information on each item below please go to product page part number

#0515-150-150 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE
Class: E
Diameter: 15"
Pitch: 15"
Gearcase: 4-3/4"
Blades: 3
Rotation: RH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: 9511-150-15

#0515-148-170 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE
Class: E
Diameter: 14-3/4"
Pitch: 17"
Gearcase: 4-3/4"
Blades: 3
Rotation: RH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: 9511-148-17

#0515-145-190 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE
Class: E
Diameter: 14-1/2"
Pitch: 19"
Gearcase: 4-3/4"
Blades: 3
Rotation: RH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: 9511-145-19

#0515-143-210 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE
Class: E
Diameter: 14-1/4"
Pitch: 21"
Gearcase: 4-3/4"
Blades: 3
Rotation: RH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: 9511-143-21

---

3 BLADE RH ROTATION E+ CLASS
List of Compatible KDP Ultra 7X Series High-Strength Alloy Interchangeable Outboard Propellers
NOTE: for more information on each item below please go to product page part number

#0515-158-130 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE
Class: E+
Diameter: 15-3/4"
Pitch: 13"
Gearcase: 4-3/4"
Blades: 3
Rotation: RH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: 9511-160-13

#0515-160-150 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE
Class: E+
Diameter: 16"
Pitch: 15"
Gearcase: 4-3/4"
Blades: 3
Rotation: RH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: 9511-158-15

#0515-160-170 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE
Class: E+
Diameter: 16"
Pitch: 17"
Gearcase: 4-3/4"
Blades: 3
Rotation: RH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: N/A

#0515-160-185 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE
Class: E+
Diameter: 16"
Pitch: 18-1/2"
Gearcase: 4-3/4"
Blades: 3
Rotation: RH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: N/A

#0515-160-200 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE
Class: E+
Diameter: 16"
Pitch: 20"
Gearcase: 4-3/4"
Blades: 3
Rotation: RH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: N/A

#0515-160-215 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE
Class: E+
Diameter: 16"
Pitch: 21-1/2"
Gearcase: 4-3/4"
Blades: 3
Rotation: RH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: N/A

---

3 BLADE LH ROTATION E+ CLASS
List of Compatible KDP Ultra 7X Series High-Strength Alloy Interchangeable Outboard Propellers
NOTE: for more information on each item below please go to product page part number

#0516-158-130 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE LH ROTATION
Class: E+
Diameter: 15-3/4"
Pitch: 13"
Gearcase: 4-3/4"
Blades: 3
Rotation: LH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: N/A

#0516-160-150 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE LH ROTATION
Class: E+
Diameter: 16"
Pitch: 15"
Gearcase: 4-3/4"
Blades: 3
Rotation: LH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: 9512-158-15

#0516-160-170 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE LH ROTATION
Class: E+
Diameter: 16"
Pitch: 17"
Gearcase: 4-3/4"
Blades: 3
Rotation: LH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: N/A

#0516-160-185 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE LH ROTATION
Class: E+
Diameter: 16"
Pitch: 18-1/2"
Gearcase: 4-3/4"
Blades: 3
Rotation: LH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: N/A

#0516-160-200 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE LH ROTATION
Class: E+
Diameter: 16"
Pitch: 20"
Gearcase: 4-3/4"
Blades: 3
Rotation: LH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: N/A

#0516-160-215 KDP Ultra 7X H.S.A Interchangeable Outboard Propeller - 3 BLADE LH ROTATION
Class: E+
Diameter: 16"
Pitch: 21-1/2"
Gearcase: 4-3/4"
Blades: 3
Rotation: LH
Material Type: High-Strength Alloy (H.S.A)*
Propeller H.S.A Characteristics*: Light as Aluminum, Durable as Titanium, Reliable as Stainless Steel
Made In: South Korea
Replaces Solas Propeller p/n: N/A
